About the author: Gary M. Strunak is national sales manager for Tomlinson Industries. He can be reached at 216.587.3400, or by e-mail at [email protected].
by Gary M. Strunak
undefined
Point-of-use (POU) faucets and systems are becoming increasingly important in helping meet consumer demands for safe, high quality drinking water. It is estimated that by 2020 every household will have a POU or point-of-entry (POE) water treatment system. These water treatment systems can get very fancy and require faucets in a wide variety of styles and finishes. Their appearance should be sleek, attractive and contemporary with ergometric handles, required in today’s high-end kitchens.
Perhaps the most decorative and attractive faucets available are used on sinks and water treatment systems for homes, recreational vehicles, yachts, etc. Cost is not a major factor here; function and appearance are primary issues.
Amendments to the Federal Safe Drinking Water Act required faucets and other endpoint plumbing devices to comply with the lead requirements of ANSI/NSF Standard 61, Section 9 by August 1998. Some of the products covered include drinking fountains, water coolers, hot water dispensers, glass fillers, kitchen and lavatory faucets as well as residential refrigerator icemakers.
Styles & Finishes
Faucets for POU, reverse osmosis and other water treatment systems are available in either an air-gap or non-air-gap version. The air-gap style provides protection from back-siphonage. Back-siphonage is the flowing back of used, contaminated or polluted water from a plumbing fixture or vessel into a water supply pipe due to a negative pressure (vacuum) in the pipe.
POU faucets are usually available in many different styles and finishes to help complement or match a specific décor. Some POU faucets feature an ergonomic handle, a stream straightener, a protective tip and goosenecks that swivel easily. These faucets should have a maximum temperature rating of 150°F and a maximum pressure rating of 120 psi to efficiently dispense the treated water.
Decorative or designer faucets for reverse osmosis and water treatment systems are a great up-sell for the modern homes of today. These faucets must be NSF listed to ANSI/NSF Standard 61 – 1999a.
A growing trend for POU faucets is the incorporation of motion sensors to activate the water flow. The user can simply place a glass under the spout and does not need to turn or press a handle.
Lead Problems
An unsafe level of lead in drinking water is an old and ongoing issue. This situation can occur as a result of lead pipes or fixtures that have lead solder. Unsafe lead levels have been found in older drinking water systems. The U.S. Environmental Protection Agency (EPA) recommends that lead levels in drinking water be below 15 parts per billion (ppb).
Lead-free faucets are the answer to lead problems occurring in older drinking water equipment and systems in public areas such as restaurants, hotels, parks and schools.
An area of concern is public schools. Some school systems have initiated plans to replace their old drinking fountains with newer models. Test results in schools showed that many of their bubbler fountains had unsafe levels of lead in the drinking water.
The faucets used on the indoor and outdoor drinking water fountains can be either the “bubbler” style or the “projector head.” The bubbler incorporates the activator button right into the faucet, which controls the flow. The projector head allows for the activator button to be located away from where the water is being dispensed, such as on the side of the cooler or fountain. This is quite common. The projector head simply provides the flow characteristics for drinking. An interesting option available with the projector head is a “set screw” that allows for protection from vandals. This is especially popular with outdoor fountains. Bubblers and projector heads should be lead-free and NSF-certified.
Fountain Glass Fillers
Fountain Glass Fillers feature lead-free brass construction with a chrome-plated finish and a lever-actuated flow. The unique internal design provides a smooth flow through a wide range of pressures without the need for a flow-control design. The fountain glass fillers have a 3⁄8-in. NPS connection and are available with a 5-in., 8-in. or long-reach spout. Dispensing styles include push down, push back or cup trip. Another option is a vertical mount glass filler. Fountain glass fillers should have a maximum pressure rating of 120 psi.
POU Coolers
POU water coolers offer an endless supply of refreshing water. They attach directly to the water source and never require filling or replenishing. A hidden reservoir assures there is always plenty of cold, hot or room temperature water. A variety of sizes are available ranging from countertop models to larger floor model drinking water fountains. Both floor models and wall-mounted models are available in a variety of styles, sizes and configurations, including barrier-free coolers that allow for complete accessibility for wheelchairs. Some of the new water coolers actually use foot pedals to activate the water flow. Both innovations have increased the number of uses and users of POU water coolers.
Some POU water systems use plastic cooler faucets. These faucets should be made of FDA grade polypropylene and be lead-free. These materials do not distort or affect the taste of the water being dispensed. The faucets should be NSF-listed and many are available in a variety of colors. Optional handles, including a “cup trip” style for one-hand dispensing and a “safety handle” design to help prevent accidental dispensing, are additional choices to enhance the unit.
Hot Water Dispensing
Other applications for POU faucets are hot water dispensing units, coffee brewers and coffee urns where water lines are plumbed directly into the unit. These faucets are dispensing very hot, sometimes boiling, water and are made of chromed brass. Both gravity and high-pressure faucets are available. Most faucets are NSF-listed and can be supplied with safety-style handles to prevent accidental dispensing. Some high-pressure faucets come standard with a safety clip and aerator for a smooth, controlled flow. When required, a spout extension can be installed on the metal faucets to ensure even more control over the dispensing of such hot liquids.
Conclusion
The key to faucet selection is safety. Avoid the inexpensive, leaded brass styles for any RO or “bubbler”-style applications. The materials used in all units, from basic to high-end, must meet requirements, such as FDA-grade materials and NSF listings on all models. The NSF certification ensures that the design and materials used provide for a safe product. Beyond that, the rest of the considerations revolve around aesthetics such as which style and color look best for a given product or specific location.
In the near future, all consumers will demand purified and/or filtered water. The consumer will choose how and where that water is treated. Consumers are already choosing to install POU systems and POE whole-house systems to obtain high quality, good tasting water. With the threat of contamination of large municipal water treatment plants, POU/POE water treatment and filtering systems will be considered a means of ensuring safe and pure drinking water within homes.
Photo: FreeImages.com/David Duncan
